31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt Hydraulic Pump Assy For R290LC7

Product Categories

Guangzhou Menzeh Machinery Parts Co., Ltd.

Contact Now

31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt Hydraulic Pump Assy For R290LC7

Name: 31N810050 31N810051 31N810060 XJBN00963 K3V140dt Hydraulic Pump Assy For R290LC7
Brand: MENZEH GEARS
Price: 1 USD

Wholesale 31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt Hydraulic Pump Assy For R290LC7 from china suppliers

Brand Name : MENZEH GEARS

Model Number : 31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt

Certification : CE

Place of Origin : GUANGZHOU CHINA

MOQ : 1pc

Price : Negotiated

Payment Terms : Western Union, T/T, L/C,ALI PAY

Supply Ability : 500 pcs per Day

Delivery Time : 1-3 working Days

Packaging Details : BOX, Wooden Case

Part Name : Hydraulic Main Pump

Part Number : 31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt

Used For : R290LC7

Condiction : All New OEM

Warrenty : 3 Months

Shipping : DHL/ TNT/ UPS/ SEA/ AIR Shipping

Port : Huangpu Guangzhou

High Light : 31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt R290LC7 Hydraulic Main Pump

After Warranty : Video technical support Online support Spare parts

Contact Now

31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt R290LC7 Excavator Spare Parts Hydraulic Main Pump

Part Name	Hydraulic Main Pump
Part Number	31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt
Used For	R290LC7
Warrenty	3 Months
After Warranty	Video technical support Online support Free Spare parts

Pos.	Part No	Qty	Parts name	Comments
*.	31N8-10010	[1]	MAIN PUMP	TIER-II
*.	31N8-10050	[1]	MAIN PUMP
*-1.	K3V140DT-1CER	[1]	MAIN PUMP UNIT
*-1.	K3V140DT-1CER-B	[1]	MAIN PUMP UNIT
111	XJBN-00015	[1]	SHAFT-DRIVE(F)
113	XJBN-00153	[1]	SHAFT-DRIVE(R)
114	XJBN-00367	[1]	COUPLING-SPLINE
123	XJBN-00017	[2]	BEARING-ROLLER
124	XJBN-00018	[2]	BEARING-NEEDLE
127	XJBN-00019	[3]	SPACER-BEARING
S141.	XJBN-00007	[2]	BLOCK-CYLINDER
NS151.	XJBN-00004	[18]	PISTON
NS152.	XJBN-00748	[18]	SHOE
153	XJBN-00020	[2]	PLATE-SET
156	XJBN-00021	[2]	BUSHING-SPHERICAL
157	XJBN-00022	[18]	SPRING-CYLINDER
158	XJBN-00368	[2]	SPACER
211	XJBN-00023	[2]	PLATE-SHOE
S212.	XJBN-00012	[2]	PLATE-SWASH
S214.	XJBN-00013	[2]	BUSHING-TILTING
251	XJBN-00024	[2]	SUPPORT
261	XJBN-00025	[1]	COVER(FR)-SEAL
271	XJBN-00026	[2]	CASING-PUMP
312	XJBN-00027	[1]	BLOCK-VALVE
S313.	XJBN-00008	[1]	PLATE(R)-VALVE
S314.	XJBN-00010	[1]	PLATE(L)-VALVE
401	XJBN-00028	[8]	SCREW
406	XJBN-00355	[4]	SCREW-HEX SOC HD
466	XJBN-00356	[2]	PLUG
468	XJBN-00357	[4]	PLUG
490	XJBN-00032	[29]	PLUG
NS531.	XJBN-00369	[2]	PIN-TILTING
532	XJBN-00033	[2]	PISTON-SERVO
534	XJBN-00034	[2]	STOPPER(L)
535	XJBN-00035	[2]	STOPPER(S)
N541.	XJBN-00036	[4]	SEAT
N543.	XJBN-00037	[2]	STOPPER 1
N544.	XJBN-00039	[2]	STOPPER 2
545	XJBN-00359	[4]	BALL-STEEL
NS548.	XJBN-00360	[2]	PIN-FEED BACK
702	XJBN-00040	[2]	O-RING
710	XJBN-00041	[1]	O-RING
717	XJBN-00042	[2]	O-RING
719	XJBN-00043	[2]	O-RING
724	XJBN-00361	[16]	O-RING
725	XJBN-00362	[4]	O-RING
728	XJBN-00363	[3]	O-RING
732	XJBN-00047	[2]	O-RING
774	XJBN-00906	[1]	SEAL-OIL
789	XJBN-00049	[2]	RING-BACK UP
792	XJBN-00050	[2]	RING-BACK UP
808	XJBN-00364	[4]	NUT
824	XJBN-00052	[2]	RING-SNAP
885	XJBN-00053	[2]	PIN-2
886	XJBN-00365	[4]	PIN-SPRING
901	XJBN-00055	[2]	BOLT-EYE
953	XJBN-00056	[2]	SCREW-SET
954	XJBN-00057	[2]	SCREW-SET
981	XJBN-00156	[1]	NAME PLATE
983	XJBN-00341	[2]	PIN
*-2.	XJBN-00001	[1]	REGULATOR	SEE 4020
*-3.	XJBN-00002	[1]	GEAR PUMP	SEE 4030
*-3.	XJBN-00520	[1]	GEAR PUMP	SEE 4030
*-3.	XJBN-00847	[1]	GEAR PUMP	SEE 4030
*-4.	XJBN-00014	[1]	EPPR VALVE ASSY	SEE 4010
*-4.	XJBN-00382	[1]	EPPR VALVE ASSY	SEE 4041
11	XJBN-00003	[2]	PISTON SUB ASSY	SEE ILLUST
13	XJBN-00006	[1]	CYLINDER ASSY-RH	SEE ILLUST
14	XJBN-00009	[1]	CYLINDER ASSY-LH	SEE ILLUST
30	XJBN-00011	[2]	SWASH PLATE ASSY	SEE ILLUST
530	XJBN-00371	[2]	TILTING PIN ASSY	SEE ILLUST
N.	@	[1]	NOT INDIVIDUALLY SUPPLIED

31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt Hydraulic Pump Assy For R290LC7

FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.

31N8-10050 31N8-10051 31N8-10060 XJBN-00963 K3V140dt Hydraulic Pump Assy For R290LC7
